PVC flat profile cable has good insulating properties, acid and alkali resistance, flame retardancy, oil resistance and moisture resistance; stable structure, simple manufacturing process and affordable price.
Send Inquiry
Description
Technical Parameters
House Wire Supplier
PVC flat profile cable excels in several key areas: it provides excellent electrical insulation and withstands exposure to acids, alkalis, oils, and moisture. It's also flame retardant. Beyond its performance, the cable boasts a stable design, a relatively simple manufacturing process, and an affordable price point.
Basic Info.
Voltage level：
450/750V
Implementation standard:
GB/T5023.3-2008
Maximum conductor temperature:
70℃
Laying environment
Power devices, fixed wiring, daily appliances, meters, lighting fixtures and telecommunication equipment with AC voltage 450/750V and below
BV: Copper-core PVC-insulated wire, is a single core of copper wire, more rigid, also called hard wire.
BVR: copper core PVC insulated soft wire, is a single core wire with multiple strands of copper wire twisted together, also called soft wire.
RVV: copper core PVC insulated PVC sheathed soft wire, commonly known as soft sheathed wire, that is, 2, 3 or 4 RV wires sheathed together with a sheath.
Q: What is the application of this cable?
A: PVC flat profile cable is a kind of soft wire for distribution cabinet, also called secondary wire. It is used in applications where softness is required for fixed wiring. The maximum temperature of the conductor is 70℃ during normal use. It is suitable for fixed wiring of power devices with AC rated voltage 450/750V and below.
PVC flat profile cable can be used for home lighting, fixed wiring can be used for indoor open laying, through the pipe and other occasions, in order to facilitate the difference in the installation process, grams were red, yellow, blue, green, black, white, double a total of seven colors. Because BVR is soft structure, the scope of application is also more in the soft environment.
